36-inch Rollomatic: new bar needs 114 drive links, not 113
Bar 3003 000 9852 takes 113 links; revised 3003 000 9853 takes 114. Same outer contour as the 1.3 mm bar does not mean the same groove gauge.
- The original Rollomatic E Super bar 3003 000 9852 has a 3/8-inch nose sprocket, 1.6 mm / 0.063-inch groove and 90 cm / 36-inch nominal length, and requires a 3/8-inch chain with 113 drive links. The modified contour of 3003 000 9853 requires 114 drive links. The TI describes 114 as the international norm for this length; this is not a rule for every 36-inch bar or powerhead.
- The summary row specifies 3/8 inch - 13 T for this bar. The 13 T value is the nose-sprocket tooth count, NOT a chain drive-link count or a powerhead sprocket specification. The bar-tail illustration confirms 3003 000 9853, 1.6, 3/8, 90 cm / 36 inches and 114; identify the modified bar by its marked PART NUMBER AND DRIVE-LINK COUNT.
- The NEW bar outer contour is identical to 3003 000 9653, whose groove is 1.3 mm / 0.050 inch. The shared contour does NOT establish chain-gauge interchange. No exact powerhead fitment list, chain order number, mounting modification or conversion procedure is supplied; none is inferred from series 3003.
- The heading and prose call the bar Rollomatic E Super; the summary calls it Rollomatic S. Both designations are retained as source wording, not silently standardized. Old 3003 000 9852 is factory-supplied only while stocks last (remark 1); new 3003 000 9853 has MOQ H 1. The key cell is blank.
- Introduction is “in progress”: no serial cutoff or completed rollout date. The next Cutting Attachments for Chain Saws catalog is to be amended; that future editorial promise is not needed for this self-contained change. Last TI 01.95 is bibliographic. Footer February 1, 1995, ©1995 Andreas Stihl, D1/MTK Technical Documentation; issue 13.95 is not a month.
- Historical TI guidance only; factory availability is historical, not current stock. Exact-model IPL links are navigation, not proof of unrestricted interchange. No hardware operation was performed.
