New STIHL guide bars – Series 3002
STIHL 3/8" Rollomatic® E Super These guide bars are for use on 084, 088, and MS
guide bars 880 chain saws
3/8" chain can be run on these saws if the drive
Two STIHL Rollomatic® E Super versions have sprocket on the saw is changed to 3/8“ pitch.
been added to the range of STIHL guide bars:
Adding these longer versions completes STIHL’s
Version Bar length Groove width
current line of 3/8 pitch Rollomatic® E Super guide
3002 000 9031 25“ (63 cm) 0.63“ (1.6 mm) bars.
88 drive links
3002 000 9041 30“ (75 cm) 0.63“ (1.6 mm)
100 drive links
The new guide bars have a 3/8" bar nose with a
13-tooth sprocket and type 3002 bar mounting.
Color-coding is yellow.
Summary
Item Part name Part No.
1 Guide bar
Rollomatic® E Super 63 cm; 1.6 mm; 3/8“ 3002 000 9031
2 Guide bar
Rollomatic® E Super 75 cm; 1.6 mm; 3/8“ 3002 000 9041
3 Bar nose 3/8", 13 teeth, 1.6 3003 650 2539
